Description

Dynaset HSP 2600/5-50 hydraulic driven submersible pump for foul water with a maximum flow rate of 3000 Litres Per Minute (LPM).

The compact size and durable design enables this hydraulic submersible pump to tolerate mud and water containing solid substances such as rocks. Key features include:

• Versatile, easy to move
• Lightweight
• High efficiency
• Safe to use
• Reliable
• Safe to run dry and does not wear out
• Low maintenance
• Two year or 2000 hour warranty
• Robust and simple design
• Tolerates solids and abrasive substances
• Tolerates mud, rocks, chop hay, rootstocks and other substances without clogging
• No electricity, no risk of electric shock
• Requires only the hydraulic connection of pressure and return line to work
• Hardox impeller creates a powerful pumping action
• No wearing parts



Applications include:

• Large quantity water pumping
• Draining excavations
• Sludge pumping
• Feed pumping e.g. drill fluids
• Flood pumping solutions
• Container filling
• Construction work sites and flooded areas



The Dynaset HSP 2600/5-50 submersible pump is very high quality and made in Finland.

Water Power Output:

• Maximum Water Flow – 3000 Litres Per Minute
• Water Flow @ 5 Metre Head – 2600 Litres Per Minute
• Maximum Pump Head – 35 Metres
• Outlet – 3″ BSP Female



Hydraulic Power Input:

• Maximum Pressure – 250 Bar / 3626 PSI
• Maximum Oil Flow – 50 Litres Per Minute
• Max Tank Pressure – 10 Bar / 145 PSI
• Hydraulic Motor – Gear
• Oil Viscosity Range – 10 to 200 cSt (Optimum 25 to 35 cSt)
• Maximum Oil Temperature – 70°C
• Minimum Oil Filter Ratio – 25 μm
• Oil Cleanliness Level ISO 4406 – 19/17/14
• Hydraulic Inlet – 1/2” BSP Female
• Hydraulic Outlet – 3/4” BSP Female



Weight & Dimensions:

• Weight – 20KG
• Length – 350mm
• Width – 350mm
• Height – 700mm



Please contact us if you are unsure whether this will suit your application.

We are an official Dynaset distributor for the UK and Ireland.
