Description

Flojet LF Plus Series 12V diaphragm pump (RLFP122201D) with santoprene diaphragm, viton check valve and an output of 1.7 bar / 25 PSI at 3.8 litres per minute. It is a demand pump.

This chemical resistant diaphragm pump is suitable for a range of fluid transfer applications. Not approved for pumping fuels.

This Flojet LF Plus Series pump is perfect for acid, soft washing, clean water, fluid transfer, agricultural spraying, herbicides, pesticides, tree spraying, lawn sprayers, garden sprayers, pest control, greenhouses, livestock spraying, fence spraying and much more.

Details:

• Supply – 12 Volt DC, 3.5 Amps
• Maximum Operating Pressure – 1.7 Bar / 25 PSI
• Maximum Flow – 3.8 Litres Per Minute
• Working Fluid Temperature – 2 to 43°C
• Self-priming up to 1.8 metres
• Viton Check Valve
• Santoprene Diaphragm
• No Bypass
• Integrated Pressure / Demand Switch
• Polypropylene Housing
• Width – 102.9mm
• Height – 67.6mm
• Length – 164.3mm
• Inlet Port – 3/8″ Hose Barb
• Outlet Port – 3/8″ Hose Barb
• Intermittent Duty Cycle

Please contact us if you are unsure whether this will suit your application.
