Flojet Triplex Hi-Pressure 12V Diaphragm Pump 10.3 Bar 5.3 L - EPDM

Flojet Triplex Hi-Pressure 12V Diaphragm Pump 10.3 Bar 5.3 L – EPDM

£ 244.99 inc. VAT

Flojet Triplex Hi-Pressure 12V diaphragm pump (R3811143A) with santoprene diaphragm, EPDM check valve and an output of 10.3 bar / 149 PSI at 5.3 litres per minute. It is a demand pump.

SKU: DPU-000052 Category:
Flojet

Description

Flojet Triplex Hi-Pressure 12V diaphragm pump (R3811143A) with santoprene diaphragm, EPDM check valve and an output of 10.310 bar / 149 PSI at 5.3 litres per minute. It is a demand pump.

This chemical resistant diaphragm pump is suitable for a range of fluid transfer applications. Not approved for pumping fuels.

Details:

  • Supply – 12 Volt DC, 10.0 Amps
  • Maximum Operating Pressure – 10.3 Bar / 149 PSI
  • Maximum Flow – 5.3 Litres Per Minute
  • Max Fluid Temperature – 60°C
  • Self-priming up to 2.4 metres
  • EPDM Check Valve
  • Santoprene Diaphragm
  • Integrated Pressure / Demand Switch
  • Glass Filled Nylon Pump Housing
  • Inlet Port – 3/8″ NPT Female
  • Outlet Port – 3/8″ NPT Female



Please contact us if you are unsure whether this will suit your application.

Additional information

Weight 3.85 kg
