Hypro 9303S-HM1C-U Hydraulic Driven Centrifugal Pump
£ 2,274.99 inc. VAT
Hypro 9303S-HM1C-U hydraulic driven centrifugal pump. It has an AISI 316 stainless steel body, viton seals and an output of 8.9 bar / 129 PSI at 431 litres per minute.
Description
Hypro 9303S-HM1C-U hydraulic driven centrifugal pump. It has an AISI 316 stainless steel body, viton seals and an output of 8.9 bar / 129 PSI at 431 litres per minute.
This version has manifold ports.
This is a very high quality centrifugal pump.
Details:
-
Maximum Pressure – 8.9 Bar / 129 PSI
-
Maximum Flow – 431 Litres Per Minute
-
Non Self-Priming
-
Hydraulic Motor Driven
-
Body Material – AISI 316 Stainless Steel
-
Viton Seals
-
Maximum Oil Pressure – 150 Bar / 1450 PSI
-
Maximum Oil Flow – 49 Litres Per Minute
-
Inlet – 220 2″ FP Manifold
-
Outlet – 200 2″ FP Manifold
-
Motor Port In – 1/2″ NPT Female
-
Motor Port Out – 3/4″ NPT Female
-
Carbon Ceramic Mechanical Seal
-
Glass Filled Polypropylene Impeller
Please contact us if you are unsure whether this will suit your application.
Additional information
Weight | 12.98 kg |
---|
