Description

Marco UP10/E 12V & 24V gear pump electronic brain unit. It has an integrated check valve, electronic pressure sensor, helicoidal PTFE gears, nickel plated brass pump body, viton seals, buna o-rings and an output of 5 bar / 73 PSI at 18 litres per minute.

This Marco UP10/E 12V & 24V gear pump is perfect for freshwater and sanitary water systems on a boat, camper etc.

The electronic pressure sensor is controlled by a microprocessor: the variable speed control (RPM) of the electric motor is proportional to the flow rate demand and has the advantage of reducing noise level, current consumption and mechanical wear and tear compared to the traditional mechanical pressure switch.

The pump is protected against short circuits and overloads, there is no need for a fuse. The electronic system will attempt to re-start the motor 4 times and will gradually increase the flow rate until it reaches the required level. Pump functions are monitored by an LED and a blue light indicates an empty tank.

Details:

• Supply – 12 & 24 Volt DC, 25 Amps
• Maximum Operating Pressure – 5 Bar / 73 PSI
• Maximum Flow – 18 Litres Per Minute
• Max Fluid Temperature – 40°C
• Max Suction – 3 Metres
• Self-Priming
• Integrated Check Valve
• Electronic Pressure Sensor
• Pump Body Material – Nickel Plated Brass
• Helicoidal PTFE Gears
• Viton Seals
• Buna O-Rings
• Inline Filter (Not for flooded feed)
• Width – 193mm
• Height – 109mm
• Length – 240mm
• Inlet Port – 3/8″ BSP Female
• Outlet Port – 3/8″ BSP Female
• Includes 2x 13mm Brass Hose Barbs

Please contact us if you are unsure whether this will suit your application.
