Description

Marco UP10/PN 12V gear pump electric motor driven unit. It has helicoidal PTFE gears, nickel plated brass pump body, viton seals, buna o-rings and an output of 7 bar / 102 PSI at 18 litres per minute.

This Marco UP10/PN 12V gear pump is perfect for clean water and antifreeze.

Details:

• Supply – 12 Volt DC, 30 Amps
• Maximum Operating Pressure – 7 Bar / 102 PSI
• Maximum Flow – 18 Litres Per Minute
• Max Fluid Temperature – 40°C
• Max Suction – 3 Metres
• Self-Priming
• Pump Body Material – Nickel Plated Brass
• Helicoidal PTFE Gears
• Viton Seals
• Buna O-Rings
• Inline Filter (Not for flooded feed)
• Width – 173.8mm
• Height – 103.2mm
• Length – 211.7mm
• Inlet Port – 3/8″ BSP Female
• Outlet Port – 3/8″ BSP Female
• Includes 2x 13mm Brass Hose Barbs

Please contact us if you are unsure whether this will suit your application.
