Marco UP10/PN 12V Gear Pump Electric Motor Unit 7 Bar 18 LPM

£ 341.99 inc. VAT

Marco UP10/PN 12V gear pump electric motor driven unit. Perfect for clean water and antifreeze. It has helicoidal PTFE gears, a nickel plated brass pump body, viton seals, buna o-rings and an output of 7 bar / 102 PSI at 18 litres per minute.

SKU: GPU-000010 Category:
Marco

Description

Marco UP10/PN 12V gear pump electric motor driven unit. It has helicoidal PTFE gears, nickel plated brass pump body, viton seals, buna o-rings and an output of 7 bar / 102 PSI at 18 litres per minute.

This Marco UP10/PN 12V gear pump is perfect for clean water and antifreeze.

Details:

  • Supply – 12 Volt DC, 30 Amps
  • Maximum Operating Pressure – 7 Bar / 102 PSI
  • Maximum Flow – 18 Litres Per Minute
  • Max Fluid Temperature – 40ยฐC
  • Max Suction – 3 Metres
  • Self-Priming
  • Pump Body Material – Nickel Plated Brass
  • Helicoidal PTFE Gears
  • Viton Seals
  • Buna O-Rings
  • Inline Filter (Not for flooded feed)
  • Width – 173.8mm
  • Height – 103.2mm
  • Length – 211.7mm
  • Inlet Port – 3/8″ BSP Female
  • Outlet Port – 3/8″ BSP Female
  • Includes 2x 13mm Brass Hose Barbs



Please contact us if you are unsure whether this will suit your application.

Additional information

Weight 4.18 kg
