Description

The System Cleaners BS10 water booster pump station provides a boosted water supply for open plant cleaning solutions in the food and beverage industry.

This frequency controlled pump will provide up to 10 independent satellite stations with a boosted water supply of up to 20 bar. It requires suitable water and three phase electrical supplies as detailed below.

It should be placed in a separate technical room, or similar, to protect it from the processing environment and comes with a frame that can be bolted to the floor.

This System Cleaners BS10 water booster pump station is very high quality and Danish made.

Pump:

• Pump Type – Grundfos CRNE 15-9
• Motor – 14.75HP / 11kW
• Number of Operators Simultaneously – Up to 10

Water Supply:

• Connection – 2″ BSP Female
• Minimum Flow Rate – 375 Litres Per Minute
• Minimum Inlet Pressure – 1.5 Bar / 23 PSI
• Maximum Inlet Pressure – 10 Bar / 145 PSI
• Temperature – 3 to 70°C

Electrical:

• Voltage & Frequency – 400V 50Hz

Outlet:

• Maximum Outlet Pressure – 20 Bar / 290 PSI
• Maximum Flow Rate @ 20 Bar (Inc. 4 Bar Inlet Pressure) – 300 Litres Per Minute
• Connection – 2″ BSP Female

Weight & Dimensions:

• Height – 1550mm
• Width – 615mm
• Length – 445mm
• Weight – 210KG



Please note that this product has a 2 to 4 week delivery time.

Please contact us if you are unsure whether this will suit your application or if you require a different specification to what is listed here.
